Defect #43371
open
Icon images are not displayed in the text editor
0%
Description
Icon images are not displayed in the text editor.
Environment:
- Redmine version 6.1.0.stable
- Ruby version 3.3.8-p144 (2025-04-09) [x86_64-linux-gnu]
- Rails version 7.2.2.2
- Environment production
- Database adapter PostgreSQL
- Mailer queue ActiveJob::QueueAdapters::AsyncAdapter
- Mailer delivery smtp
Redmine settings:
- Redmine theme Default
SCM:
- Mercurial 7.0.1
- Git 2.47.3
- Filesystem
Redmine plugins:
- redmine_wiki_extensions 1.1.0
Screen:
:(
Files
Updated by f0x Autumn 1 day ago
bundle exec rake assets:precompile RAILS_ENV=production
- not helped
Updated by f0x Autumn 1 day ago
According to the messages in the browser's debug console, the issue appears to be with the virtual host configuration in Apache2 (?):
GET https://my_site_url/assets/jstoolbar/underline-7f1532c4.svg [HTTP/1.1 403 Forbidden 1ms]
For some reason, after upgrading from 5.1.x or 6.0.7 to 6.1.0, the Redmine root, which should be https://my_site_url/redmine/ and consequently
https://my_site_url/redmine/assets/jstoolbar/underline-7f1532c4.svg, is being ignored for the /var/www/redmine/assets directory.
However, I have not changed the Apache2 virtual host configuration since the beginning, for all Redmine versions I've used since 4.x.x.
Currently digging in this direction.
Updated by f0x Autumn 1 day ago
Exactly. The issue was in the order of Apache directive processing. The <LocationMatch "^(?!/(redmine|dokuwiki))"> directive was blocking access BEFORE the request could reach Passenger.
Solution: Move the restrictive LocationMatch directive below the Redmine configuration blocks to prevent it from blocking access BEFORE the request reaches Passenger.
Issue is resolved, can be closed.
